Product Description
This product contains a built-in core which may be returned to us for reimbursement.
Bendix K079670 M-40QR Remanufactured ABS Modulator Valve 12V
The Bendix K079670 M-40QR ABS Modulator Valve is a remanufactured pneumatic braking component designed to provide reliable brake pressure control in heavy-duty commercial vehicles equipped with antilock braking systems (ABS). Its quick-release design helps provide responsive brake application and release, improving braking control during demanding operating conditions.
Working in conjunction with the vehicle's ABS electronic control unit, the M-40QR modulator regulates compressed air delivered to the brake chambers. During ABS activation, the valve responds to electronic signals by holding or releasing brake pressure as needed, helping prevent wheel lockup and maintain vehicle stability.
The M-40QR incorporates a quick-release function that allows compressed air to exhaust rapidly during brake release. This design supports responsive braking performance and helps reduce delays in pressure reduction.
Featuring 12-volt electrical operation, a three-way sealed electrical connector and 1/2-inch NPT air connections, the Bendix K079670 is designed for dependable service in compatible commercial truck air brake systems.
Product Features:
-
Genuine Bendix M-40QR ABS modulator valve
-
Manufacturer part number K079670
-
Remanufactured replacement assembly
-
Quick-release pneumatic modulator design
-
12-volt electrical operation
-
Three-way Metri-Pack 280 Series electrical connector
-
1/2-inch NPT supply and delivery ports
-
Maximum operating pressure of 150 PSI
-
Electronically controlled brake pressure modulation
-
Supports ABS braking system operation
-
Helps reduce wheel lockup during hard braking
-
Integrated quick-release function
-
Two mounting holes for secure installation
-
Durable construction for heavy-duty commercial vehicle service
Technical Specifications:
-
Manufacturer: Bendix
-
Part Number: K079670
-
Model: M-40QR
-
Product Type: ABS Modulator Valve
-
Condition: Remanufactured
-
Modulator Type: Quick Release (QR)
-
Operating Voltage: 12V DC
-
Nominal Current: 4.6 Amps
-
Maximum Operating Pressure: 150 PSI
-
Supply Port: 1/2"-14 NPT
-
Delivery Port: 1/2"-14 NPT
-
Exhaust Port: Dust Shield
-
Electrical Connector: Metri-Pack 280 Series Three-Way Sealed Male
-
Duty Cycle: 15 Seconds / 5 Minutes
-
Maximum Solenoid On Time: 150 Seconds
-
Mounting: Two 0.335-inch diameter holes
-
Minimum Operating Temperature: -40°F
-
Maximum Operating Temperature: 185°F
-
VMRS Code: 013-011-071
-
Remanufactured Reference: K079670X
