Product Description
This part contains a core which may be returned to us for reimbursement.
The Bendix L55314 is a loaded 2.60-inch twin-piston hydraulic brake caliper designed for medium-duty International/Navistar trucks and buses.
The L55314 uses a second-design Bendix caliper with a high-mounted hydraulic inlet and press-in piston boots. It features two 2.60-inch phenolic pistons and is commonly associated with casting number 4151733.
The “L” prefix identifies this as a loaded caliper configuration, meaning the caliper is supplied with brake pads and mounting hardware. The 55314 family is designed for use on either the left or right side, depending on the vehicle and axle configuration.
Part Number: L55314
Base Part Number: 55314
Brand: Bendix
Product Type: Loaded Hydraulic Disc Brake Caliper
Caliper Design: Twin Piston
Piston Diameter: 2.60 in.
Piston Material: Phenolic
Casting Number: 4151733
Hydraulic Inlet: 7/16-24
Inlet Location: High / Top
Brake Pad Type: D184
Bendix Pad Set: MK184
Mounting Hardware: Included
Brake Pads: Included
Position: Left or Right depending on vehicle configuration
Typical Vehicle Family: International / Navistar medium-duty trucks and buses
Common Cross References: 55314, L55314, L55314M, 55314LX, RH55314LX, R55314, R42R55314, E14675006, E146750062, 4151733
Always verify the original caliper number, casting number, piston diameter, hydraulic inlet location, axle position, and vehicle brake configuration before ordering.
