Product Description
Webb 65541B 15 x 4 Balanced Front Brake Drum – 3158X / 123312
The Webb 65541B is a 15 x 4-inch balanced cast-iron brake drum with an outboard mounting configuration. It features a 9.00-inch pilot diameter, 11.25-inch bolt circle, and 10-hole mounting pattern.
Gunite 3158X and Meritor/Dayton 123312 are established interchanges for the 65541B. Other recognized numbers include KIC 54241-018, Motor Wheel 88114B, Ford D8HZ-1125-D, and Gunite 3407X. The 9-inch pilot and 1.31-inch mounting holes are useful identifying measurements when comparing this drum with other 15 x 4 drums.
Part Number: 65541B
Product Type: Heavy-Duty Front Brake Drum
Brand: Webb
Brake Size: 15 x 4 in.
Brake Surface Diameter: 15.00 in.
Brake Shoe Width: 4.00 in.
Brake Surface Flat: 4.50 in.
Overall Depth: 8.76 in.
Outside Diameter: 17.12 in.
Mounting Type: Outboard
Drum Type: H
Material: Cast Iron
Balance: Balanced
Pilot Diameter: 9.00 in.
Bolt Circle Diameter: 11.25 in.
Bolt Holes: 10
Bolt Hole Diameter: 1.31 in.
Back Plate Thickness: 0.62 in.
Maximum Wear Diameter: 15.12 in.
Approximate Weight: 77 lb
ABS Tone Ring Included: No
Outer Cooling Fins: No
Gunite Cross References: 3158, 3158X, 3407, 3407X
Meritor / Dayton Cross Reference: 123312
KIC Cross References: 52981-01, 54241-018
Motor Wheel Cross References: 88114, 88114B, 88116
Ford Cross Reference: D8HZ-1125-D
International / Navistar Cross Reference: 1608459C1
Automann Cross Reference: 151.5405BA
Additional Cross References: 14541X, 8058703, 819952, 821-9184, X-60491, ZBR3158X
Inventory Description: 3158X FRONT DRUM 123312
Before ordering, confirm the 65541B number or a verified interchange, along with the 15 x 4 brake size, 9.00-inch pilot, 11.25-inch bolt circle, 10-hole pattern, 1.31-inch mounting holes, and outboard mounting configuration to ensure proper fit.
