Product Description
The WAI 24-1505 Alternator Pulley is a heavy-duty 3-groove V-belt pulley designed for compatible Delco 27SI / Type 205 alternators used on Chevrolet, GMC, and International commercial truck applications.
WAI catalogs the 24-1505 as a machined cold-rolled steel pulley designed for 13 mm belts. It measures approximately 73 mm (2.87 inches) in outside diameter and uses a 22.23 mm (7/8-inch) bore.
The pulley replaces Delco 2048694 and is intended for heavy-duty charging systems requiring a three-groove V-belt drive. A current equivalent listing also identifies the pulley as approximately 22.2 × 73 × 55.9 mm overall.
Specifications:
- Part Number: 24-1505
- Brand: WAI
- Product Type: Alternator Pulley
- Grooves: 3
- Groove Type: V-Belt
- Belt Size: 13 mm / approximately 1/2 in.
- Outside Diameter: 73 mm / 2.87 in.
- Bore: 22.23 mm / 7/8 in.
- Overall Width: Approximately 55.9 mm / 2.20 in.
- Alternator Series: Delco 27SI / Type 205
- Applications: Chevrolet, GMC Truck, International / IHC Truck
- Material: Machined cold-rolled steel
- Replaces: Delco 2048694
Cross References:
- Delco: 2048694
- Aftermarket: 203-01001
- Aftermarket: HT-0059
