Product Description
This part contains a core which may be returned to us for reimbursement.
The Wagner F42193 Hydraulic Brake Master Cylinder is a heavy-duty replacement master cylinder designed for select Ford hydraulic brake systems. Built with a durable cast-iron body, it provides the hydraulic pressure needed to operate the vehicle's service brakes.
The F42193 features a 1-3/4" bore and 1/2"-20 threaded ports. Catalog information identifies casting number FE41207 for this master cylinder.
Specifications:
- Part Number: F42193
- Brand: Wagner Brake
- Type: Hydraulic Brake Master Cylinder
- Bore: 1-3/4"
- Port Thread: 1/2"-20
- Casting Number: FE41207
- Construction: Cast iron
- Vehicle Type: Medium- and heavy-duty Ford trucks
- Brake System: Hydraulic
Common interchange references include Wagner MC42193, Centric 130.79007, Raybestos MC36177, Midland 42193, Bendix 11432, and Ford C3TZ-2140-K / C3TZ-2140-M.
Always compare the part number, casting number, bore size, port configuration, and existing master cylinder before ordering.
