Product Description
Optronics WLL01AHLHB amber LED mini directional warning light designed for commercial trucks, service vehicles, and other applications requiring high-visibility safety lighting. This compact round warning light features six yellow LEDs behind a clear polycarbonate lens, with up to 12 selectable flash patterns, steady-burn operation, and an off setting.
Designed for 12V and 24V electrical systems, the WLL01AHLHB operates on 10–30 volts and features an aluminum housing with an IP67 rating for dust and water resistance. The surface-mount design includes a gasket and trim ring for installation.
The light features 144-inch hardwired leads with connections for power, ground, flash pattern selection, synchronization, and steady-burn operation. Multiple compatible lights can be synchronized for coordinated warning signals.
Meets SAE J595 Class 1 requirements and includes a five-year manufacturer warranty.
Verify electrical requirements, mounting dimensions, and intended application before ordering.
