Product Description
The part contains a built-in core which may be returned to us for reimbursement.
Bendix 281560N TH-3 Three-Position Air Brake Control Valve
The Bendix 281560N TH-3 Three-Position Air Brake Control Valve is a manually operated pneumatic control valve designed for use in heavy-duty commercial vehicle air brake systems. Featuring a three-position flipper-style actuator, this valve provides controlled air pressure routing for compatible parking brake, emergency brake and auxiliary pneumatic circuits.
The TH-3 valve features a positioning mechanism that allows the operator to select and maintain one of three operating positions. Its compact design and durable construction make it suitable for commercial truck environments where dependable pneumatic control is essential.
Manufactured with a black nylon actuator and precision-engineered internal components, the Bendix 281560N offers reliable operation across a wide range of temperatures. Its 1/8-inch NPT threaded connections provide compatibility with appropriately configured pneumatic systems.
Product Features:
-
Genuine Bendix TH-3 three-position control valve
-
Manufacturer part number 281560N
-
New aftermarket service replacement
-
Three-position manually operated flipper-style actuator
-
Positioning mechanism maintains the selected lever position
-
Black nylon actuator
-
100-degree total lever travel
-
1/8-inch NPT pneumatic connections
-
Two threaded mounting holes
-
Designed for commercial vehicle pneumatic control systems
-
Compact construction for dashboard or panel installation
-
Maintenance kit reference: Bendix 282391
Technical Specifications:
-
Manufacturer: Bendix
-
Part Number: 281560N
-
Model: TH-3
-
Product Type: Three-Position Air Control Valve
-
Condition: New
-
Actuator Style: Flipper
-
Actuator Material: Nylon
-
Actuator Color: Black
-
Mechanism Type: Positioning
-
Total Lever Travel: 100 Degrees
-
Supply Port 1: 1/8"-27 NPT
-
Supply Ports 2, 3 and 4: Closed
-
Delivery Port 1: 1/8"-27 NPT
-
Delivery Port 2: 1/8"-27 NPT
-
Exhaust: Vent
-
Mounting: Two #10-24 UNC-3B threaded holes
-
Minimum Operating Temperature: -40°F
-
Maximum Operating Temperature: 200°F
-
Maintenance Kit: Bendix 282391
