Product Description
The WABCO 4721950940 is a heavy-duty ABS solenoid modulator valve designed for tractor and commercial vehicle anti-lock braking systems. The valve electronically controls air pressure at the brake chamber during ABS operation, allowing the ABS controller to reduce, hold, or restore braking pressure as needed.
The 4721950940 operates on 12 volts and uses a bayonet-style DIN electrical connector. WABCO specifies 1/2"-14 Dry Seal NPTF air ports, a maximum operating pressure of 159.5 PSI, and an operating temperature range of approximately -40°F to 176°F. WABCO Customer Centre
Part Number: 4721950940
Brand: WABCO / ZF
Product Type: ABS Solenoid Modulator Valve
Position: Left-Hand / LH
Voltage: 12V
Connector: Bayonet DIN
Ports: 1/2"-14 Dry Seal NPTF
Maximum Operating Pressure: 159.5 PSI
Cross References: S4721950940, S472-195-094-0, TDAS4721950940, WAB4721950940, 6300-4721950940
