Product Description
This part contains a core which may be returned to us for reimbursement.
The Bendix 2513129 is a heavy-duty Convac vacuum pump designed to provide vacuum for vacuum-operated brake and vehicle systems. This engine-driven pump features clockwise rotation and a 2.24-inch shaft.
The 2513129 is an engine-lubricated, end-cover style pump with a 0.250-inch vacuum/oil inlet and a non-threaded oil-air outlet located at the base. Bendix identifies the pump with code 3129 and lists 2501454 as the current service replacement.
Built for commercial truck and heavy-equipment vacuum systems, this pump is commonly associated with older vehicles equipped with Bendix Convac-style vacuum brake components.
Part Number: 2513129
Brand: Bendix
Product Type: Convac Vacuum Pump
Identification Code: 3129
Rotation: Clockwise
Shaft Length: 2.24 in.
Vacuum/Oil Inlet: 0.250 in.
Oil-Air Outlet: Non-threaded
Outlet Location: Base
Lubrication: Engine lubricated, end-cover type
Bendix Service Replacement: 2501454
VMRS: 13-008-032
Device Code: 6610
Product Weight: Approximately 15 lb.
Always verify the part number, rotation, shaft length, mounting configuration, ports, and vehicle requirements before ordering. Some older Convac pump installations may require reuse of existing fittings or other components when replacing the original pump.
