Product Description
The part contains a built-in core which may be returned to us for reimbursement.
Bendix 801932 ATR-3 ABS Traction Relay Valve 12V – 4 PSI
The Bendix 801932 ATR-3 ABS Traction Relay Valve is a heavy-duty pneumatic braking component designed to support dependable braking and traction control in commercial vehicles equipped with antilock braking systems (ABS) and automatic traction control (ATC).
This valve combines conventional air brake relay functionality with electronically controlled traction braking capabilities. During normal service braking, the valve helps deliver compressed air from the vehicle's reservoirs to the appropriate brake circuits. When traction control intervention is required, the integrated solenoid allows the electronic braking system to manage brake pressure and help reduce excessive wheel spin.
Featuring a 12-volt electrical system, a 4.0 PSI crack pressure and a twist-lock electrical connector, the Bendix 801932 is engineered for reliable pneumatic operation in demanding commercial truck environments.
Product Features:
-
Genuine Bendix ATR-3 ABS traction relay valve
-
Manufacturer part number 801932
-
Combines air brake relay and automatic traction control functions
-
Supports ABS and ATC braking systems
-
12-volt electrical operation
-
4.0 PSI crack pressure
-
Twist-lock electrical connector
-
1/2-inch NPT delivery ports
-
Helps improve traction during low-grip driving conditions
-
Responsive pneumatic brake pressure control
-
Durable construction for heavy-duty commercial truck service
-
Direct service replacement for Bendix OE part number 5014494
Technical Specifications:
-
Manufacturer: Bendix
-
Part Number: 801932
-
Model: ATR-3
-
Product Type: ABS Traction Relay Valve
-
Operating Voltage: 12V DC
-
Crack Pressure: 4.0 PSI
-
Electrical Connector: Twist-Lock / Bayonet
-
Supply Port: 1/2"-14 NPT
-
Control Port: 1/4"-18 NPT
-
Delivery Ports: Four 1/2"-14 NPT
-
Exhaust Port: Dust Shield
-
Mounting: Three 3/8"-16 UNC-2B threaded mounting holes
-
Mounting Bracket: Not included
-
Minimum Operating Temperature: -40°F
-
Maximum Operating Temperature: 185°F
-
OE Reference: 5014494
-
Bendix Service Replacement: K078219 (ATR-6)
Bendix's catalog identifies 801932 as an ATR-3 traction relay valve with 4.0 PSI crack pressure, a 12V supply and no mounting bracket. Bendix also confirms that K078219 is its designated ATR-6 replacement for this assembly.
