Product Description
The Bendix 55098 Hydraulic Disc Brake Caliper is a new, unloaded right-hand single-piston caliper designed for medium-duty commercial vehicle hydraulic brake systems.
Bendix identifies the 55098 as a 3.38-inch single-piston caliper commonly used on Navistar/International medium-duty truck applications. The caliper uses a U.S.-standard hydraulic inlet port and bleed screw and is associated with casting number 2238452R. Bendix pairs the 55098 with the 55099 left-hand caliper for the opposite side.
The caliper provides the hydraulic clamping force needed to press the disc brake pads against the rotor during braking. Its large 3.38-inch piston is designed for the higher braking demands of medium-duty trucks, buses, and commercial chassis.
Bendix catalogs the 55098 with MKD184-family brake pads, H5634 hardware, and H8203 key-and-shim components in its medium-duty hydraulic brake literature.
Specifications:
- Part Number: 55098 / 055098
- Brand: Bendix
- Product Type: Hydraulic Disc Brake Caliper
- Position: Right Hand
- Piston Count: 1
- Piston Diameter: 3.38 in.
- Hydraulic Connection: U.S.-standard inlet
- Bleeder: U.S.-standard bleed screw
- Casting Number: 2238452R
- Configuration: Unloaded / pads not included
- Typical Application: Navistar / International medium-duty trucks
- Condition: New
- Remanufactured Equivalent: R55098 FinditParts
Cross References:
- Bendix: 055098
- Bendix Reman: R55098
- Euclid: E-4235
- Centric: 141.66011
- Dorman: 604-230
- Haldex: 85357
- Raybestos: RWC5098 / FRC4087 / FRC4088
