Product Description
The Bendix 801128 Foot Brake Valve is a heavy-duty, pedal-operated air brake control assembly designed for commercial trucks equipped with dual-circuit air braking systems. It provides controlled application and release of air pressure, allowing drivers to regulate service braking through a suspended foot pedal.
This assembly includes a cast aluminum brake pedal, pedal pad, and mounting plate. Its dual-circuit construction independently controls primary and secondary braking circuits, helping maintain braking capability if one circuit loses air pressure.
The 801128 features multiple threaded supply and delivery ports, a 1/2"-14 NPT exhaust port, and a rubber graduation spring for responsive brake pedal operation. Designed for demanding commercial vehicle environments, it supports reliable braking performance during everyday operation.
Before ordering, verify the original valve part number, mounting configuration, pedal offset, and air port sizes to ensure proper compatibility.
Product Specifications
-
Manufacturer: Bendix
-
Part Number: 801128
-
Valve Type: E-7 style dual-circuit foot brake valve
-
Pedal Style: Suspended
-
Pedal Material: Cast aluminum
-
Pedal Included: Yes
-
Pedal Pad Included: Yes
-
Mounting Plate Included: Yes
-
Overall Pedal Length: 10.10 inches
-
Pedal Offset: 3.25 inches left
-
Differential Pressure: 3 PSI
-
Exhaust Port: 1/2"-14 NPT
-
Operating Temperature: -40°F to 200°F
-
Compliance: FMVSS 121
